The REV Robotics Control Hub is an affordable all-in-one educational robotics controller. It provides students all the necessary interfaces for robotics and mechatronics projects with multiple programming language options.
The Control Hub is purpose-built to stand up to the rigors of the classroom and the competition field with ESD and reverse polarity protection. Running the Android operating system gives the Control Hub the flexibility to control both basic and advanced robots while also being field-updatable as new features are developed.
The Control Hub must run v5.0 or higher of the Robot Controller application and paired with a v5.0 or higher Driver Station application. To make sure your Control Hub is running the latest software, use the REV Hardware Client.
Specifications
- Actuator interfaces
- Control position and velocity of DC motors
- Small and easy to control actuators
- 4 - DC motor ports with built-in encoder ports
- 6 - Servo motor ports
- Sensor and device interfaces
- 8 - Digital input/output ports
- 4 - Analog input ports
- 4 - Independent I2C ports
- 1 - Internal 6-axis IMU
- Additional expansion interfaces
- Connect additional Expansion Hubs to add more actuator and sensor ports
- 2 - RS485 ports
- Currently supported programming languages
- Blocks
- OnBot Java
- Java
Kit Contents
| SKU | PRODUCT NAME | PRODUCT QUANTITY | PACK QUANTITY |
| REV-31-1595 | Control Hub | QTY 1 | |
| XT30 Extension Cable, 30cm | QTY 1 | ||
| 3-pin JST PH Cable, 30cm | QTY 1 | ||
| USB-A Male to USB-C Cable | QTY 1 |
Documentation
- TITLE-UM
- Getting Started with the Control Hub
- Hello Robot: Introduction to Programming - Blocks
- Hello Robot: Introduction to Programming - OnBot Java
- Control Hub Troubleshooting Guide
- REV Hardware Client User's Manual
- Videos:
Notes
- For the 2020-2021 season, FIRST Tech Challenge teams in all regions will have the option of using the REV Robotics Control Hub within the FTC Competition environment. Information on this option can be found in this video published by FIRST Tech Challenge.
CAD & Drawings
- SKU-STP
