The SPARK Flex is a new smart motor controller that is compatible with the REV ION System. Its dockable form factor allows for the direct mounting onto a NEO Vortex, simplifying wiring while maintaining flexibility. Improving upon the...

The Flex Dock transforms the SPARK Flex (REV-11-2159) into a standalone motor controller, supporting REV brushless motors and virtually any 12V brushed DC motor by providing standard phase wire outputs. The 6-pin JST PH encoder port is compatible with...

The MAXSpline Encoder delivers high accuracy and robust performance while integrating seamlessly with the MAXSpline ecosystem. Using the same proven magnetic sensing architecture as the Through Bore Encoder V2, this model adds expanded connectivity...

The REV Power Distribution Hub (PDH) is the latest evolution in power distribution for the FIRST Robotics Competition (FRC).  With 20 high-current (40A max) channels, 3 low-current (15A max), and 1 switchable low-current channel, the PDH...

The REV USB PS4 Compatible Gamepad is compatible with both the REV DUO and REV ION Systems. Plug the REV Gamepad directly into a Driver Hub to enable feature rich control of your robot. Additionally, when plugged into a PC, it offers an Xbox...

The REV Pneumatic Hub is a standalone module that is capable of switching both 12V and 24V pneumatic solenoid valves. The Pneumatic Hub features 16 solenoid channels which allow for up to 16 single-acting solenoids, 8 double-acting solenoids, or a...

Touch sensor is best used for user input, but can also be used as a limit switch.  Configuration The REV Touch Sensor is a digital sensor that is wired to the N+1 channel on our standard 4-pin JST PH connector. In other words, the REV Expansion Hub...

Now legal for both FTC and FRC! Blinkin makes adding LEDs to your robot as simple as driving a motor. Chose the pattern you want and give it the corresponding PWM signal. The REV Robotics Blinkin LED Driver is a compact LED driver module that simplifies...

The Servo Power Module is a 6V 90W power injector that enables the use of high-power RC servos in applications where a robot controller cannot directly provide adequate power.  The Servo Power Unit passes through input signals unaltered while...

The REV Robotics SRS Programmer is the key to unlocking all the smart features of the (SRS) Smart Robot Servo (sold separately). Switching between continuous rotation, standard servo, and custom angular modes is easy as pressing a button. The...

2-pin header cable that can be used for connecting signals, sensors or any other spots on robots. Features 2 female 0.1in pitch connectors on each end.  Specifications Length: 91cm (36in) 2 pin receptacle on 0.1in pitch Wire Colors: red, black 22...

The Molex MicroFit+ Power and CAN Cable is the dedicated replacement and accessory cable for the MAXSpline Through Bore Encoder. It provides both power and CAN connectivity through a compact, secure 2x2 Molex MicroFit+ latching connector. While currently...

The Digital LED Indicator is a LED signal module that is digitally controlled (active low) and offers three colors: red, green, and amber. The Digital LED Indicator is designed to directly interface with the DIO ports of the Expansion Hub or Control Hub...

The 36in CAN Extension Cable is a 3-pin connector to interface with existing CAN devices.  Specifications Length: 36in (3ft) Wire Colors: yellow, green 22 AWG

Connect the REV Through Bore Encoder directly to the SPARK MAX Data Port when it is configured in Alternate Encoder Mode using this adapter. This adapter is not intended for use with the default Data Port configuration or with other...

These JST PH 6-pin Joiner Boards are intended to be used with the JST PH 6-pin Extension Cables to extend the reach of your NEO Brushless Motor sensor cables.

This JST-PH 6-pin Breakout Board is designed to adapt external sensors to the SPARK MAX 6-pin Encoder Port standard. It features a JST PH 6-pin connector, labeled solder pads, and through-hole pads that are compatible with popular 63R style quadrature...

These plastic clips are designed to keep standard 0.1" 3-pin PWM connectors together. Simply clip them around an assembled pair of connectors.

PWM Cables, which are used for connecting things like the SPARK Motor controller to the roboRIO. These can also be used as servo extension cables for getting signal and power a bit farther away than integrated wires can reach. Specifications Length:...

The NEO 2.0 Sensor Cable connects the NEO 2.0 Brushless Motor’s sensor port to a standard JST PH 6-pin interface used on REV motor controllers. The 2x3-pin PHSD connector provides a secure, latching connection at the motor, while the 6-pin JST PH...
