FIRST Tech Challenge

The FTC Starter Kit V3.1 is the ultimate starting point for your team’s FIRST Tech Challenge season. Built based on feedback directly from teams, this kit is packed with essential REV DUO components you need to design, prototype, and compete...

The DUO Control Bundle offers basic FTC-legal control system components to get an existing robot up and running. Pair the DUO Control Bundle with the DUO EDU Mechanical Kit (REV-45-2708) to get started with our curriculum, Intro to Robotics V2...

Featuring the REV Driver Hub, an easy to use, dependable, and durable device designed for interfacing with the Control Hub. Featuring an Android operating system and built-in dual band Wi-Fi, this device makes getting your robot running easier than...

The EDU Kit V2 was specifically created to implement hands-on STEM projects in the classroom. This upgrade bundle bridges the gap between the EDU Kit V2 (REV-45-2041) and the FTC Starter Kit V3.1 (REV-45-3529), providing the needed equipment to...

The REV USB PS4 Compatible Gamepad is compatible with both the REV DUO and REV ION Systems. Plug the REV Gamepad directly into a Driver Hub to enable feature rich control of your robot. Additionally, when plugged into a PC, it offers an Xbox...

The REV UltraPlanetary Gearbox Kit is the entry point into using the REV UltraPlanetary System. The kit comes with UltraPlanetary Cartridges to support six different final gear reductions ranging from nominally 3:1 to 60:1 allowing for the right amount...

REV Building System also comes in a 15mm x 30mm square extrusion. The slots are designed to fit standard M3 hardware rather than expensive t-nuts. Use the 15mm x 30mm extrusion when more strength is needed for an application. For smaller applications the...

DUO Omni Wheels are compatible with the REV DUO System and have rollers mounted around the outside which passively rotate at 90 degrees to the powered direction of the wheel. DUO Omni Wheels can be used to make it easier to turn with skid steer...

Touch sensor is best used for user input, but can also be used as a limit switch.  Configuration The REV Touch Sensor is a digital sensor that is wired to the N+1 channel on our standard 4-pin JST PH connector. In other words, the REV Expansion Hub...

DUO Grip Wheels are used for intakes, conveyor systems, and shooters. With a solid 5mm Hex Hub molded into the wheel no external hub is required. These wheels come in two different durometers, Soft - Light Gray 30A and Medium - Gray 40A. As the tread...

DUO Compliant Wheels are used for intakes and conveyor systems. Featuring a solid 5mm Hex Hub molded into the wheel making sure more power is driven by the wheel, combined with the “hurricane” cutouts to ensure even compliance across the...

Metal sprockets designed to work in high-load applications with #25 chain. Specifications Chain Size: #25 Material: Sintered Steel CAD & Drawings REV-41-1716 STEP File REV-41-1716 Onshape REV-41-1716 Drawing

UltraPlanetary Brackets are compatible with the REV DUO System. Each bracket includes holes on an 8mm grid that is compatible with many other building systems. The UltraPlanetary Outside Mounting Bracket (REV-41-1621) is used to...

DUO Flap Wheels are compatible with the REV DUO System and feature a 5mm Hex Bore. They are used on intakes to pick up irregular gamepieces, playing a similar role to compliant wheels. While compliant wheels provide compliance with minimal slip between...

With an efficient right-angle configuration, the Ultra 90 Degree Gearbox offers a robust solution to building a more compact robot. The Ultra 90 Degree Gearbox allows you to connect the UltraPlanetary Gearbox and the HD Hex Motor (REV-41-1600)...

Replacement battery for the Driver Hub (REV-31-1596). Specifications 5040 mAH Li-ion battery  Documentation Driver Hub User's Manual Driver Hub Getting Started Guide

This sensor can be used to read and compare colors, and also has a built-in IR (optical) Proximity Sensor and white LED for active target lighting. Supports High Speed I2C Communication (400kHz) as well as auto increment register read which allows the...

The #25 Chain Turnbuckle is compatible with both the REV ION System and REV DUO System. It is designed to adjust the length of a #25 Chain by replacing a few links in a run and also allows the user to tension the chain by adjusting the...

Tested for the rigors of competition, REV Mecanum Wheels are steel plates with rollers supported by ball bearings allowing for the perfect combination of wheel rigidity and roller movement. Included in the set of wheels are Universal Hex Adapter making...

Now legal for both FTC and FRC! Blinkin makes adding LEDs to your robot as simple as driving a motor. Chose the pattern you want and give it the corresponding PWM signal. The REV Robotics Blinkin LED Driver is a compact LED driver module that simplifies...
